Composite Panel

48 Hour Production

Aluminium Composite Panel (ACP) is widely regarded as the most premium outdoor signage material, having surpassed Colorbond as the industry standard for long-term signage. With a smooth surface and lightweight yet rigid construction, Composite Panel delivers exceptional print clarity and durability. We print directly to the substrate using UV flatbed technology, ensuring high-quality results that hold up over time.

Ideal for permanent signage installations, wall panels, and even decorative ceiling features, Composite Panel is the go-to choice when longevity and presentation matter.

We supply Composite Panel in a wide range of custom sizes up to 2400mm x 1200mm. Please follow the link below for pricing on Composite Panel options for your customers.

Size

Enter the Width and Height required

Job Summary

Sub total

$—.—

GST

$—.—

Total price

About

Benefits

Sustainability

FAQ

Download

Composite Panel

Our Composite Panel signs are produced on premium 3mm ImageBond Lite Aluminium Composite Panel (ACP) — a professional-grade material designed for superior print performance, rigidity, and durability. Each sheet features two 0.21 mm aluminium skins bonded to a solid polyethylene core, creating a perfectly flat and dimensionally stable surface for high-quality signage.

Using direct UV flatbed printing, we achieve vibrant colour reproduction and excellent detail with a clean, satin finish. Each panel is precision-cut on our Zünd router to your specified contour, ensuring a consistent, professional result every time.

While the ImageBond Lite substrate is engineered for up to 8 years of outdoor use, the printed UV ink layer is rated for up to 2 years of outdoor exposure under normal Australian conditions. This makes Composite Panel ideal for premium indoor or short-term outdoor signage, retail displays, architectural panels, and branded feature walls.

Rigid & Long-Lasting

Constructed from two aluminium layers bonded to a polyethylene core, Composite Panel provides exceptional rigidity, impact resistance, and dimensional stability. It maintains its flatness and professional appearance even under varying temperature conditions, perfect for displays requiring a premium, durable finish.

Router Cut to Shape

Each sign is router-cut to your specified contour on our precision Zünd digital cutter. We support simple shapes with clean, smooth outlines (up to five points) to ensure high-quality results and efficient production.

Sustainability

Recyclable Aluminium & Core

Both the aluminium skins and the polyethylene core are fully recyclable, allowing the panels to be re-processed through approved metal and plastic recycling streams, supporting circular manufacturing and reducing landfill waste.

Certified Sustainable Production

ImageBond Lite is manufactured under ISO 9001 and ISO 14001 certification and is REACH, RoHS, and CE compliant. These global standards ensure consistent quality, worker safety, and environmentally responsible production across every panel.

Low-VOC & Durst Ink Technology

Printed with Durst POP Flexible LED inks, our process uses VOC-free UV-curable technology cured with low-energy LED lamps. This minimises emissions, reduces power consumption, and delivers sharp, colour-accurate results, aligning with sustainable print practices.

FAQ

What thickness is available for Composite Panels?

We offer 3mm ImageBond Lite Aluminium Composite Panel only. This thickness provides the best balance between strength, rigidity, and weight for professional-grade signage.

What is the maximum sheet size?

The maximum printable area is 1200 × 2400 mm, suitable for most display, wall-mounted, or retail signage applications.

Can Composite Panel be used outdoors?

Yes. The panel itself is rated for up to 8 years outdoors, but the printed UV ink layer is designed for up to 2 years of outdoor exposure. It’s ideal for long-term indoor displays and medium-term outdoor use.

What printing method is used?

We print directly onto the panel using UV flatbed technology. This method produces a durable, scratch-resistant finish with vivid colours and sharp detail. We do not apply additional coatings or laminates over the print surface.

Is double-sided printing available?

No. Composite Panel is available as single-sided print only to ensure a smooth, uniform finish and precision routing on the rear side.

Do you offer additional finishing options?

We print and route only. We do not offer drilling, taping, lamination, or framing, ensuring consistent automated production and fast turnaround times.

Can I order custom shapes?

Yes. Panels can be router-cut to your specified contour for a clean, precise edge. Simple convex or contour shapes are supported for optimal quality and finish.

Is the panel fire-rated?

ImageBond Lite carries a fire rating of B-s1, d0. However, if your application requires strict fire-protection compliance or construction-grade certification, this product may not be suitable. We recommend consulting with the relevant certifier, builder, or fire engineer to confirm material suitability through another supplier, as we would not recommend this stock where absolute fire-rating certainty is required.

What are typical production turnaround times?

Orders under $1,000 + GST are produced within two business days after artwork approval. For each additional $2,000 + GST, please allow one extra business day.

Do you offer express production?

No. All orders are queued in order of artwork approval to maintain fairness, efficiency, and consistency for all trade customers.

Can Composite Panels be recycled?

Yes. Both the aluminium skins and the core materials can be recycled through approved metal and plastic recovery programs, contributing to sustainable signage disposal.

Can I order a sample before a large job?

Yes. We recommend ordering a small printed sample to confirm colour accuracy, surface finish, and edge quality before proceeding with larger production runs.

Why does pricing change in steps instead of increasing evenly with quantity?

Composite Panel pricing is calculated using a true cost, sheet based production model rather than square metre pricing. Panels are produced and printed in full sheet sizes, meaning pricing may remain the same across certain quantity ranges and then step up only when an additional panel is required. This reflects the actual cost of materials, machining, handling, and waste, ensuring transparent pricing with no hidden cost recovery. Compared to square metre pricing models, this approach delivers clearer cost alignment and more predictable outcomes for trade customers.

Can you make exceptions to finishes or turnaround times for one-off Composite Panel orders?

No. Composite Panel orders must be submitted using the options and turnaround times available in our system, and we’re unable to accommodate one-off changes outside of those parameters. Our production model is designed around standardised workflows that ensure consistent quality and delivery. If you identify a long-term opportunity driven by volume or market demand, we welcome that feedback for future review.

Download

Composite Panel Technical Material Datasheet

This technical datasheet outlines the material specifications of aluminium composite panels used in print-only signage, including panel construction, available thicknesses, weight, fire rating, durability, and performance characteristics. Featuring aluminium surface skins bonded to a polyethylene core and optimised for direct-to-sheet UV digital printing, composite panels offer excellent rigidity, weather resistance, and print quality, making them suitable for medium- to long-term indoor and outdoor signage applications.

ImagebondCompositePanel_TechnicalDataSheet

97.6kb

Composite Panel Print Only Artwork Guidelines

This document outlines the required artwork setup and file preparation standards for composite panel print-only signage, including bleed and trim box setup, colour mode, file format requirements, overprint handling, and Thru-cut setup for custom shapes or holes. Following these guidelines ensures artwork is supplied print-ready and helps minimise production delays, errors, or rework during printing and CNC finishing.

Mediapoint_Boards_ArtworkGuidelines

1.3mb
